1PCS 12Vdc Outdoor WaterProof Security Home Burglar Alarm DG85 Wall-Mounted Dual PIR Sensor Wire Infrared Motion Detector

$38.91$41.30

Estimated Delivery Dates: Dec 18, 2024 - Dec 30, 2024
SKU: 2251832659456671 Category: Tags: , , , , ,

Description

  • Model Number: dg85
  • Brand Name: SAIFULI
  • Origin: Mainland China
  • Certification: CE
  • Smart home platform: NONE
  • color: white/grey
  • working volt: 9-16VDC
  • current: 30mA at 12VDC
  • detection range: max 11.6*11.6m
  • detection angle: 110degree
  • alarm output: NC.100mA 28VDC
  • installation height: 2-3meter
  • motion test: 0.-3.5m/s
  • humidity: 5% to 95%(RH)

(1 PCS) Outdoor Water Proof Function Burglar Alarm DG 85 Wire Type Wall-Mounted Dual PIR sensor inside Motion Detector

Note:This PIR sensor can not working alone ,when it detection somebody ,it will trigger a relay signal,you must use it to alarm system or others equipment

Technicals:
sensor type:Dual element infrared*2
sensor geomentry:rectangular
coverage:11m*11m(35ft*35ft)90 degree viewing angle
installation height:2m to 3m(7ft to 9ft)
operating temperature:-35 to 50 degree
voltage:9-16VDC
lens:2nd generation fresnel lens sefments
alarm output:Form A Relay 100mA/28VDC,NC
anti-temper switch:Form A relay 100mA/28VDC,NC
RFI/EMI rejection:10V/M
detection speed:0.2m/s to 3.5m/s
ingress protection level:IP45

Additional information

Ships From

CHINA

Color

Grey No holder, Grey with holder, white No Holder, white with Holder
